DEAN Steel "Scout" Prototype Size Medium Plus
Historically, DEAN wasn’t solely a titanium bike manufacturer. Throughout the years, the team experimented with a number of different frame materials — aluminum, carbon, stainless steel, you name it. We figured it was time we tinkered with running a classic steel MTB frame and now we have a sample for sale. We have worked with a lot of collaborators in the past and this instance is no different. In prototyping this frame, we worked with the folks at Neuhaus Metalworks and Yang Manufacturing to work out the process of fabricating steel frames with the efficiencies of additive manufacturing. They did a great job helping us work our some of the processes. Now is your chance to try the prototype rig.
Feel free to reach out directly: info@deanbikes.com
DEAN Steel "Scout" Prototype Size Medium Plus
Historically, DEAN wasn’t solely a titanium bike manufacturer. Throughout the years, the team experimented with a number of different frame materials — aluminum, carbon, stainless steel, you name it. We figured it was time we tinkered with running a classic steel MTB frame and now we have a sample for sale. We have worked with a lot of collaborators in the past and this instance is no different. In prototyping this frame, we worked with the folks at Neuhaus Metalworks and Yang Manufacturing to work out the process of fabricating steel frames with the efficiencies of additive manufacturing. They did a great job helping us work our some of the processes. Now is your chance to try the prototype rig.
Feel free to reach out directly: info@deanbikes.com

TECH SPECS:
Brake Routing
External
Shift RoutingExternal
Dropper RoutingInternal
Headtube:is42/28.6//is52/40 (Cane Creek 40 Series Headset Included)
Seatpost diameter31.6
Brake Standard: iso
Axle Standard148x12
ST length (center to top)440
Actual TT length (center to center)615
CS length
428
HT length130
Tire Clearance: 29x2.6
Crank Clearance: Boost 34t max
Weight: 5.8lbs
Designed In collaboration with Neuhaus Metalwoks and Yang Manufacturing
